Insulating Marco Twin Scissor Lift Table for Outdoor Environments and Applications
  • Name

Insulating Marco Twin Scissor Lift Table for Outdoor Environments and Applications

Detail Information
Product Description
Detail Information
Certification:
CE
Feature:
Insulating
Transport Package:
Wooden Package
Specification:
CE
Trademark:
Marco
Origin:
Ningbo, China
HS Code:
8428909090
Application:
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism:
Scissor Lift
Carrying Capacity:
Weight Level
Moves:
Stationary
Driven Type:
Hydraulic
Running Mode:
Stationary
Customization:
Available | Customized Request
Product Description

When handling long and cumbersome items the lift table type Marco Twin Lift Table can offer the best solution.

Marco Twin Lift Table is designed with two or multiple sets of scissors placed end to end to achieve the requested platform length and lifting capacity. In principle, this range consists of a combination of several Marco single scissors.

The lifting stroke of the scissors set is created by a controlled synchronism to perform a parallel lifting motion.

Main Specification:
1.Standard Options

Pump: Europe brand
Control box- dead man control with up/down/E-stop

Cylinder: Marco designing, OEM made, including rupture valve, damping action and pilot valve

Sealing kit for cylinder: SKF brand

Motor: Hoyer motor, protection IP55

Scissor arm: Q345B

Hydraulic hose/fitting: Eaton

Paint: Finland brand - Tikkurila

2.Options extra:Depends on your require

Our Services:
1. For all your inquires about us , we will reply you in detail within 24 hours
2. We own well-tranied and passional sales  and after- sale services who can speak fluent Engligh language
3. We can provide customise solutions to particular requirements
Packaging & Shipping:
Main Loading Port: ShangHai or Ningbo
Production Delivery: 6-8 weeks  (public holiday excluded)


Hot sales for 4-5 Ton Marco twin lift table with CE approved:
Art.No. Type Capacity   ( kg) Platform (L*W) Lift Height                (mm) Own Height            (mm) Lift time               (s) Motor (kw) Weight (kg)
860224 M3-040110-D4/2L 4000 3650*1000 1100 300 44 2.2 890
860226 M3-040130-D4/2L 4000 4050*1200 1300 340 27 4.6 1120
860227 M3-040160-D4/2L 4000 4550*1200 1600 340 33 4.6 1220
860228 M3-040160-D4/2LB 4000 4550*2000 1600 340 33 4.6 1570
860229 M3-040200-D4/2L 4000 6000*1500 2000 340 45 4.6 1700
860231 M3,5-040200-D4/2L 4000 6000*2000 2000 340 45 4.6 2070
860232 M3-050110-D4/2L 5000 3650*1000 1100 300 44 2.2 1000
860233 M3-050130-D4/2L 5000 4050*1200 1300 340 27 4.6 1270
860234 M3,5-050160-D4/2L 5000 4550*1200 1600 340 33 4.6 1520
860236 M3,5-050160-D4/2LB 5000 4550*2000 1600 340 33 4.6 2000
860237 M3,5-050200-D4/2L 5000 6000*1500 2000 340 57 4.6 2140
860238 M4-050200-D4/2LB 5000 6050*2000 2000 400 66 4.6 2850
